Produktdetails:
|
|
| Herkunftsort: | China |
|---|---|
| Markenname: | Glawall |
| Zertifizierung: | SGS, ISO 9001,UL, CE |
| Modellnummer: | Vollmodulare Doppelglaswand |
| Dokument: | 25mm.pdf |
|
Zahlung und Versand AGB:
|
|
| Min Bestellmenge: | 10 quadratisches Maters |
| Preis: | US$80.00 10 - 99 square meters |
| Verpackung Informationen: | Sperrholz |
| Lieferzeit: | 20-25 Tage |
| Zahlungsbedingungen: | L/C, D/A, D/P, T/T, Western Union |
| Versorgungsmaterial-Fähigkeit: | 3000 m2 pro Monat |
|
Detailinformationen |
|||
| Vorteil: | Wettbewerbsfähiger Preis, guter Service, hohe Professionalität, Qualitätsgarantie | Ort von Origi: | Guangdong, China |
|---|---|---|---|
| Fabrikzertifizierung: | Ja | Fabrikfläche: | 20000 Quadratmeter |
| Material: | Aluminiumrahmen, Akustikplatten | Schalldämmung: | 38-45db |
| Tafeldicke: | 60, 90,108 mm | Glasart: | mit einer Breite von nicht mehr als 20 mm |
| Belüftung: | Luftstromsystem | Gewährleistung: | 2 Jahre |
| Hervorheben: | 90mm aluminum partition wall,double glass modular partition,aluminum frame partition system |
||
Produkt-Beschreibung
| Advantage | Competitive price, good service, high professional, quality guarantee |
| Place of Origin | Guangdong, China |
| Factory Certification | Yes |
| Factory Area | 20000 square meter |
| Material | Aluminum Frame, Acoustic Panels |
| Soundproofing | 38-45dB |
| Panel Thickness | 60, 90, 108mm |
| Glass Type | Strong tempered glass |
| Ventilation | Airflow System |
| Warranty | 2 Years |
| Feature | Benefit |
|---|---|
| Pre-Assembled Double Glass Panels | Complete 5+5mm glass panels with integrated frame - no on-site assembly |
| Plug-and-Play Channels | Simple installation with top/side/bottom aluminum tracks |
| Tool-Free Connection | Patented click-lock system secures panels without tools |
| Fast Installation | 2-person team can install 20m² in under 3 hours |
| 42dB Soundproof Rating | 10mm air gap effectively blocks office noise |
| Thermal Insulation | Reduces HVAC costs by maintaining stable temperatures |
| Step | Action |
|---|---|
| Step 1 | Install aluminum tracks (ceiling/floor/sides) using laser level |
| Step 2 | Slide pre-assembled glass units into steel keel - no heavy lifting required |
| Step 3 | Snap decorative covers over joints for perfect alignment |
| Feature | Specification |
|---|---|
| Frame | 90mm powder-coated aluminum (20+ RAL colors) |
| Glass | 5+5mm tempered (clear/frosted/tinted options) |
| Acoustics | 42dB Rw (upgradable to 48dB with laminate) |
| Fire Rating | EI30-EI60 available |
| Max Height | 4m without additional support |
| For Contractors | For Clients |
|---|---|
| 70% faster installs = more projects per year | Immediate usability - No waiting for paint/drywall to cure |
| 50% less labor cost vs traditional systems | Adaptable layouts - Reconfigure teams without construction |
| No construction waste - LEED points achievable | Premium aesthetics - Sleek, modern appearance |
